SRC-370SH-4730 Factory Hot Selling 4.5V 17500rpm 3.63A Output 11.51W

Product Description

PMDC MOTOR Technical Data
Model		Rated Voltage (V)		No-Load		Rated				Stall
		Operating Range	Nominal	Speed	Current	Speed	Current	Torque	Power	Current	Torque
		Operating Range	Nominal	RPM	mA	RPM	mA	mN.m / gf.cm	W	mA	mN.m / gf.cm
RF-370CA 061700		6.0~24.0	24 VDC	1320	3	1000	8	0.98/10	0.1	260	4.02/41
RC-370CH 20123		3.0~6.0	6 VDC	8000	70	6878	420	2.4/24.5	1.71	2550	17/173
RC-370SH	4730	3.0~5.0	4.5 VDC	17500	550	15199	3630	7.2/73.4	11.51	24000	55/561
RC-370SH	18139	6.0~12.0	12 VDC	10000	130	8439	700	5.8/59.2	5.17	3800	37.5/382.5

Refer to the parameters above to know more details.

Application

SRC-370SH-4730 Motor Performance Diagram

SRC-370SH-4730 Engineering Specifications

Frequently Asked Questions (FAQ)

Q1: What is the operating voltage range for the SRC-370SH-4730 motor?

The operating voltage range for this model is 3.0V to 5.0V DC, with a nominal rated voltage of 4.5V DC.

Q2: What is the no-load speed and no-load current of this motor?

Under no-load conditions, the motor runs at 17500 RPM with a current of 550 mA.

Q3: What is the maximum output power of the SRC-370SH-4730?

The maximum rated output power of this PMDC motor is 11.51W.

Q4: What are the stall specifications for this motor?

Under stall conditions, the motor has a stall current of 24000 mA and can generate a stall torque of 55 mN.m (561 gf.cm).

Q5: What are the typical applications of these micro DC motors?

These motors are widely used in home appliances, smart security systems, personal care products, electronic toys, and various automated control devices.

Q6: Are there other technical specifications available for the RC-370 series?

Yes, other options include the RF-370CA (6.0-24.0V), RC-370CH (3.0-6.0V), and RC-370SH 18139 (6.0-12.0V) to meet different load and speed requirements.
