Zonix Motor
Zonix Motor
| PMDC MOTOR Technical Data | |||||||||||
|---|---|---|---|---|---|---|---|---|---|---|---|
| Model | Rated Voltage (V) | No-Load | Rated | Stall | |||||||
| Operating Range | Nominal | Speed (RPM) | Current (A) | Speed (RPM) | Current (A) | Torque (mN.m / gf.cm) | Power (W) | Current (A) | Torque (mN.m / gf.cm) | ||
| RS-770H | 8523R | 6.0~12.0 | 12 VDC | 15000 | 2.2 | 13177 | 15.91 | 81/826.2 | 111.8 | 115 | 666.9/6802 |
| RS-775H | 25110R | 6.0~24.0 | 24 VDC | 3478 | 0.15 | 2925 | 0.75 | 44.4/452.9 | 13.35 | 4.07 | 245.7/2506 |
We specialize in producing high-quality motors with over 14 years of experience across our three production facilities. Our professional R&D, experienced engineering, and dedicated management teams ensure a reliable and pleasant manufacturing partnership.
To guarantee premium quality, we inspect every stage of the process, from incoming raw materials to final shipment testing. Quality is the core foundation of our sustainable development.
High credibility supplier with verified tracking records.
100% on-time delivery rate to keep your supply chain running smoothly.
Standard samples ready within 2 weeks; custom prototypes completed within 3 weeks.
Timely response to all customer inquiries, typically within 2 hours.
We are a dedicated factory. We have specialized in micro DC motors and DC gear motors for more than 14 years.
We accept online payments with MasterCard, Visa, PayPal, T/T, and online assurance order systems.
Yes, we can customize a suitable motor according to our customers' specific requirements.
Yes, we have CE, FCC, ISO, and other standard certifications. We can apply for additional certifications if requested.
We have professional inspection personnel stationed at every process on the production lines. Finished motors undergo intensive testing using state-of-the-art machinery including Hardness Testers, 2.5D Image Testers, Salt Spray Chambers, Life Testers, Temperature Test Machines, and Noise Testers.
Yes, the length of the shaft can be customized according to your specific requirements.
